Professional Glass Machinery Manufacture Glass Tempering Furnace & Glass Laminated Line
7 Years
| Ask Lasest Price | |
| Brand Name : | AUTO |
| Model Number : | AT-LA 3050 |
| Certification : | CE, 3C, UL, ISO |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 100 SETS/YEAR |
| Delivery Time : | 3-6 MONTHS |
Laminating Glass Making Machine 3000*5000mm
Product Description:
Bullet-proof Laminating Glass Making Machine 3000*6000 mm (4 - 60 mm) includes tilting table,washing machine,positioning table,glass sheets-combining machine,transition section,sucker frames and movable device,film rollers frame,pre-heating section,pressing section,heating section,pressing section II, titling unloading, supporting facilities such as auto-clave,air compressore,air tank,humidity controller,PVB room and etc.
Supply scope:
1. Loading table 2.Washing Machine 3. Glass Sheets Combining
Section
4. Film Laying Section 5. Unloading Table 6.Air Compressor 7.Air
Tank
8.Autoclave 9.Control System 10. Spare parts
Main Parameters(The line supporting facilities not included)
We support OEM,ODM orders.
| Type | Max.Glass Size(mm) | Total Power(kw) | Outer Size(L*W*H)(MM) | Remark |
| AT-LA2536 | 2500*3600 | 128 | 29810*8000*4000 | Width&high inludes PVB room |
| AT-LA2542 | 2500*3660 | 145 | 34310*8000*4000 | |
| AT-LA2550 | 2500*5000 | 166 | 39110*8000*4000 | |
| AT-LA2560 | 2500*6000 | 183 | 45110*8000*4000 | |
| AT-LA3042 | 3000*4200 | 175 | 34310*8000*4000 | |
| AT-LA3060 | 3000*6000 | 228 | 45110*8000*4000 |
Detailed Images:
|
|
